New MAXIMUS - All-poly class

Technical details Maximus 2700 / Maximus 2700 S:

Gross trailer weight: 2.700 kg (Braked)

Payload: 1650 kg

Inner measurements: 3560 x 1800 x 2350 mm

Total measurements: 4880 x 2360 x 2930 mm

Tyres: 195/65 R15 M+S

Standard equipment Maximus 2700 / Maximus 2700 S:

• Longitudinal beam / EquiDrive® PLUS chassis and with automatic brake adjustment.
• Longitudinal beam / EquiDrive® PLUS S chassis and with coil spring suspension.
• Shock absorbers mounted.
• Polyester structure, available in several colours.
• Lockable saddle compartment with detachable feeding troughs, including lighting, extendable saddle carrier, snaffle holder, mirror, stowing net, lighting, shovel and broom.
• 13-pin plug with reversing and fog light.
• AluBiComp floor 21 mm.
• 8 mm rubber flooring, glued on and sealed.
• Entry and saddle compartment doors with 3-point locking mechanism.
• Rear ramp with high-grip rubber and sidestop.
• Side kick protection.
• 2 feeding troughs.
• Side padding left and right.
• Split and padded breast and breeching bars with panic release, height- and lengthwise adjustable.
• EquiLock® lockable partition wall.
• New designed tinted windows, 5 opening positions.
• Interior lighting.
• Exclusive roller wind deflector for draught-free interior ventilation.
• Automatic jockey wheel with shunting handle.
• Tyres designed for 60 mph.

Technical details Maximus DELUXE 2700 S:

Gross trailer weight: 2.700 kg (Braked)

Payload: 1585 kg

Inner measurements: 3560 x 1800 x 2350 mm

Total measurements: 4880 x 2360 x 2930 mm

Tyres: 195/65 R15 M+S

Standard equipment Maximus DELUXE 2700 S:

• Longitudinal beam / EquiDrive® PLUS S chassis and with coil spring suspension.
• Shock absorbers mounted.
• GRP mudguards with LED lighting.
• Polyester bodywork, available in several colours.
• Panoramic window in polyester structure.
• Door inside the saddle chamber with storage area.
• Lockable saddle compartment with detachable feeding troughs, including lighting, extendable saddle carrier, snaffle holder, mirror, stowing net, lighting, shovel and broom.
• 13-pin plug with reversing and fog light.
• AluBiComp floor 21 mm.
• 8 mm rubber flooring, glued on and sealed.
• Entry and saddle compartment doors with 3-point locking mechanism.
• Rear ramp with high-grip rubber and sidestop.
• Side kick protection.
• 2 feeding troughs.
• Side padding left and right.
• Split and padded breast and breeching bars with panic release, height- and lengthwise adjustable.
• EquiLock® lockable partition wall.
• New designed tinted windows, 5 opening positions.
• Interior lighting.
• Exclusive roller wind deflector for draught-free interior ventilation.
• Automatic jockey wheel with shunting handle.
• Tyres designed for 60 mph.
